Imported product company TIBI under various names, such AIRMATE HT-2050 or goodline HT2050. By tracing was probably manufactured in Taiwan. car space heater heater car space heater heater started suddenly car space heater turns itself off, time to check the wiring .. The left knob adjusts the temperature below which when the temperature car space heater drops in the room, turn on the fan, or even with heating. car space heater Right rotary switch controls functions such as: fan fan 1 st. heating (1000W) fan 2 st. heating (2000W)
Wiring heater in a plastic container and uses only two wires plug-reinforced shape. Switch S1 includes adjustable bimetal slow break two wire temperature drops below the set limit. Switch S2 Switches the heater. Turns gradually in parallel all the contacts. Is marked R11D11 car space heater 250V 20A. Toggle switches first fan motor together with lamp W1 (glow lamp). The second stage connected in parallel one heating element wrapped around the propeller fan. The third stage connected car space heater in parallel a second same heating element. The other ends of the two spirals are combined and connected to a thermal fuse F2. This fuse works as a protection against overheating and possible damage to the heater or fire. The circuit is still by conventional fuse F1 in the form of resistance. Due to the internal wiring can say that except for a slightly undersized conductors is a device built for stricter European market. It shows, for example, a massive 20A switch functions included several fuses and resistant plug.
